High Temperature Self Regulating HTS Heat Trace Cable

High Temperature Self Regulating HTS Heat Trace Cable

$31.99 AUD
$31.99 AUD
Sale Pre order now
GST and Shipping is calculated at checkout.
Apexio Industrial's High Temperature Self Regulating HTS Heat Trace Cable can be used for freeze protection application and process temperature maintenance. The maximum maintenance temperature is up to 150°C and continuous exposure temperature of 200°C . Whether the pipeline is overhead or buried installation, HTS heating cable can maintain the temperature and phase structure of the medium in the pipeline or vessel. It is primarily designed to provide thermal compensation solutions for large industrial pipes.
  • Energy Efficient Automatic Variable Power Output in Response to Pipe Temperature Changes.
  • High-Temperature Thermal Compensation.
  • Overlapping Safe - Non Overheating.
  • Easy Install, Cut-to-length.
  • Suitable for Non-hazardous, Hazardous and Corrosive Environments.
  • Anti-Friction/Extrusion/Inorganic.
  • Waterproof.
View full details

Technical Datasheet

Click Here to see Datasheet

Shipping

We aim to process and get your delivery with you as quick as possible.

Shipping rates and delivery times are calculated at checkout.

Guarantee

We aim to provide you with the best quality products, if for an unfortunate product defect we have a 14 day money back return guarantee.

Please see our returns policy for more information.

    • IP66/67
    • 230V
    • Maximum maintenance temperature:+150°C (302°F)
    • Maximum continuous exposure temperature:+200°C (392°F)
    • Temperature classification: T3
    • Minimum bending radius: 30mm
    • Dimensions: CT: 12.4mm (W) ×4.8mm (T)

  • Certification

    • IECEx LCI 11.0070U
    • LCIE 11 ATEX 3095 U

    Hazardous Area Classification

    • Ex e IIC Gb
    • Ex t IIIC Db
    • Ex II 2 GD

Introduction Video

Features

  • Variable Output Voltage

    Self-regulating heating cables reacts to changes in equipment or pipe temperature,
    The colder sections will receive more heat output while the warmer sections receives less. This provides greater energy efficiency and more uniform pipe temperature.

  • Overlapped Without Damage

    Because Self-Regulating cables controls its own output, overlapped sections produce less heat, eliminating “hot spots” and possible burn-through common with other types of cable.

  • Fail Safe

    Upon reaching the upper limits of its temperature range, Self-Regulating cables diminishes its own heat output to an insignificant level.

    This guarantees that maximum temperatures (T ratings) cannot be exceeded no matter what product is used in any application.

  • Pipe Freeze Protection

    In cold locations, industrial pipe insulation alone will not prevent the fluid in the pipe from freezing. Our cable combats this by compensating for heat loss, to prevent failure caused by fluid freezing.

  • Tank Heating

    The storage of liquids is important in industrial production. If the liquid in the tank solidifies or freezes, it will cause irreparable loss. Our cable provides comprehensive tank heating solutions to ensure that customers can store industrial liquids at the right temperature and minimise energy consumption.

  • Oil and Gas Rigs

    Water spattering and freezing on oil and gas RIGS or offshore vessels can threaten operations by freezing critical equipment. Our cable offers reliable heat tracing solutions that comply with Marine health and safety regulations and can be used in explosion-proof areas.
