Exd Control Station Enclosure Box - IECEx ATEX Hazardous Area Zone 1,2
Exd Control Station Enclosure Box - IECEx ATEX Hazardous Area Zone 1,2
Couldn't load pickup availability
The BZC8050 enclosure series offers excellent performance design and meets the stricter requirements of hazardous areas. Made from aluminium alloy and given an electrostatically applied plastic sprayed coating. This enables UV and thermal stability, providing mechanical impact resistance and excellent resistance when exposed either to salt mist or to marine and other damp environments. Perfect for industrial use.
Compliant to ATEX and IECEx according to EN 60079. Usually installed in industrial plants where there is a risk of explosion and fire, classified
as Zone Gas 1, 2 and Dust 21, 22; with custom configuration to be used as Control Panels, Distribution Terminal Boxes, Monitoring associated with equipment such as motors, pumps, transmitters, sensors, end cables collecting, junction etc.
SKU Model: BZC8050
Collapsible content
Technical Data
Guarantee
We aim to provide you with the best quality products, if for an unfortunate product defect we have a 14 day money back return guarantee.
Warranty
• 1 year warranty from the date of purchase.
• Invoice or shipment bill is required to claim the warranty.
• The warranty policy only requires manufacturer to repair the defective product or send substitute for replacement.
• Installation labour, electricity cost and other related cost will not be covered by the manufacturer warranty policy.
• Warranty doesn't cover the defect caused by inappropriate use, especially if directions of the instructions for use are not observed, normal abrasion as well as failures which affect the value or use of the product insignificantly.
Please see our returns policy for more information.
Shipping
Manufacturing lead time is dependant on quantity ordered. This is excluding the delivery lead time which is estimated at checkout.
We aim to process and get your delivery with you as quick as possible.
Please contact us to retrieve the estimate lead times for your order.
-
Hazardous Area Certified
Certification
- IECEx: CQM 11. 0029
- ATEX: LCIE 09 ATEX 3099
Zone Protection
IECEx
- Ex d e IIC T6 Gb
ATEX
Gas: Ex II 2 G Ex d e IIC T6 Gb
Dust: Ex II 2 D Ex tb IIIC T80℃ Db IP65
-
Customisable Configuration
- Terminal Box
- Illumination Distribution Box
- Power Distribution Box
- Control Station
- Motor Switch Panel
- Motor Stater Panel
-
Construction
- Copper free aluminium, stainless steel.
- Plastic-sprayed surface.
- Earth leakage protection device is optional.
- Degree of protection: IP66-IP67.
